¢ Models: ASYG07KMTB, ASYG09KMTB, ASYG12KMTB,
ASYG14KMTB, ASYG07KMCC, ASYG09KMCC, ASYG12KMCC,
and ASYG14KMCC
Unit: mm
(834)
Outline of indoor unit
327
273273 54
(270)
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
834
270
222
3.0
- 21 -
3-4. Wall mounted type 3. Dimensions
2-UNIT
MULTI-SPLIT TYPE
2-UNIT
MULTI-SPLIT TYPE
