Fujitsu AUXG09KVLA Service Manual

2. Dimensions
2-1. Indoor unit
¢
Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA,
AUXG18KVLA, and AUXG22KVLA
Unit: mm
285 285
Ceiling
114
B
View A
570: Indoor unit
370
540
Hanging bolt position
a: Ceiling openings
530
530
Hanging bolt position
Drain hose
A
215
19
30
123
30
262
183
Control Box
146
40
C
620
620
IR receiver
Grid type grille
View B
View C
114
a: Ceiling openings
Cassette grille (Option [Grid type]) mm 580 to 610
2-1. Indoor unit - (01-7) - 2. Dimensions
