2. Indoor unit parts list
2-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and AUXG22KVLA
3
4
1 Drain hose 9379665001
2 Hose band 9379757010
3 Pipe Thermistor 9900942038
4 Room Thermistor
9900826000
Ref. Description Part number
1
2
2-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and AUXG22KVLA - (02-2) - 2. Indoor unit parts list
