Item no. Part no. Part name Service part
1 9322556080 Top panel assy ♦
2 9710924415 Main PCB ♦
3 9900435028 Terminal ♦
4 9900727062 Thermistor assy ♦
5 9900565060 Thermistor assy (outdoor temp) ♦
6 9900984014 Heat exchanger thermistor ♦
7 9900583019 Reactor assy ♦
8 9322418005 Heat sink ♦
9 9322552112 Cabinet right assy ♦
10 9322570000 Switch cover assy ♦
11 9322144003 Drain pipe ♦
12 9322308023 Base assy ♦
13 9322555106 Front panel assy ♦
14 9387859003 Emblem ♦
15 9322135001 Blow grille ♦
16 9322136008 Propeller fan ♦
17 9603657017 Brushless motor ♦
18 9322553003 Motor bracket assy ♦
19
9322272010 Condenser total assy (for 09 model) ♦
9322273000 Condenser total assy (for 12 model) ♦
20 9322811004 Protective net ♦
21 9331404006 Thermistor holder ♦
a — Inverter assy —
3-1. Models: AOYG09KATA and AOYG12KATA - (02-8) - 3. Outdoor unit parts list
