Item no. Part no. Part name Service part
1 9322556028 Top panel assy ♦
2 9322811011 Protective net ♦
3 9322552020 Cabinet right assy ♦
4 9322570000 Switch cover assy ♦
5 9900435028 Terminal ♦
6 9710924422 Main PCB ♦
7 9900727062 Thermistor assy ♦
8 9900565060 Thermistor (Outdoor temp.) ♦
9 9900984014 Heat exchanger thermistor ♦
10
9900583019 Reactor assy (for 14 model) ♦
9900963019 Reactor assy (for 18 model) ♦
11 9322418005 Heat sink ♦
12 9322314024 Base assy ♦
13 9322144003 Drain pipe ♦
14 9322555014 Front panel assy ♦
15 9319151007 Emblem ♦
16 9322135001 Blow grille ♦
17 9322136008 Propeller fan ♦
18 9603657017 Brushless motor ♦
19 9322553010 Motor bracket assy ♦
20 9331404006 Thermistor holder ♦
21 9322275004 Condenser total assy ♦
a — Inverter assy —
b — Hair pin cushion —
3-2. Models: AOYG14KATA and AOYG18KATA - (02-12) - 3. Outdoor unit parts list
