Fujitsu AUXG18KVLA Service Manual

Separate wall
Evaporator holder 2 row
32
31
Item no. Part no. Part name Service part
31
9377914156 Evaporator total assy (For 07 model) ♦
9377914101 Evaporator total assy (For 09, 12 model) ♦
9377914118 Evaporator total assy (For 14 model) ♦
9377914125 Evaporator total assy (For 18 model) ♦
9377914149 Evaporator total assy (For 22, 24 model) ♦
32
9377764065 Insulation box sub assy (For 07, 09, 12, 14, 18 model) ♦
9377764058 Insulation box sub assy (For 22, 24 model) ♦
3-1. Models: AUXG18KVLA, AUXG22KVLA, and AUXG24KVLA - (02-9) - 3. Indoor unit parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST
