Models: ABYG24KRTA, ABYG30KRTA, ABYG36KRTA and

ABYG45KRTA

Part name Exterior Q’ty Part name Exterior Q’ty

Operating manual 1 Insulation 1

Operating manual

(CD-ROM)

1 Drain hose 1

Installation manual 1 Hose band 1

Template 1 Cable tie (large) 4

M10 nut A

(with flange)

4 Cable tie (small) 1

M10 nut B

(with spring lock

washer)

Remote controller cable

hole cap

Washer 8 Tapping screw (White) 6

Coupler heat insulation

(large)

1 Casing guard 1

Coupler heat insulation

(small)

1 Tapping screw 3

4-2. Outdoor unit

Models: AOYG18KBTB, AOYG22KBTB, and AOYG24KBTB

Part name Exterior Q’ty Part name Exterior Q’ty

Installation manual 1 Drain pipe 1

Models: AOYG30KBTB, AOYG36KBTB, and AOYG45KBTB

Part name Exterior Q’ty Part name Exterior Q’ty

Installation manual 1 Drain cap 3

Drain pipe 1 One-touch bush 2

4-1. Indoor unit - (02-25) - 4. Accessories
