Fujitsu AWTZ24LBC User Manual

4
NAME OF PARTS
Fig. 1 Indoor Unit
1 Intake Grilles
2 UV Lamp (4 position)
3 Indicator (Fig. 2)
4 MAINTENANCE SIGN Indicator Lamp (red)
5 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp flashes when the
timer is operating, it indicates that a fault has
occurred with the timer setting (See Page 24
Auto Restart).
6 OPERATION Indicator Lamp (red)
7 SUPER QUIET Indicator Lamp (green)
8 HI-POWER Indicator Lamp (orange)
9 Remote Control Signal Receiver
0 Open Panel (Fig.3)
A MAINTENANCE/MANUAL AUTO button
●
When kept on pressing the MANUAL AUTO
button for more than 10 seconds, the forced
cooling operation will start.
● The forced cooling operation is used at the
time of installation.
Only for authorized service personnel's use.
● When the forced cooling operation starts by
any chance, press the START/STOP button
to stop the operation.
B Air Filter
C Dust Box
D Air Flow Direction Louver
E Right-Left Louver
(behind Air Flow Direction Louver)
F Power Diffuser
G Power Supply Cord
H Power Supply Plug
Fig. 4 Outdoor Unit
I Intake Port
J Outlet Port
K Pipe Unit
L Drain Port (bottom)
Fig. 5 Remote Control Unit
M Signal Transmitter
N Remote Control Unit Display (Fig. 6)
O COIL DRY Display
P Operating Mode Display
Q FAN CONTROL Display
R ECONOMY Operation
S Transmit Indicator
T Temperature Display
U SWING Display
V Battery Indicator Display
W ON TIMER Display
X OFF TIMER Display
Y START/STOP button
Z SET TEMP. button (
/ )
[ COOL button
\ DRY button
] HEAT button
` SLEEP button
a AUTO button
b FAN button
c COIL DRY button
d FILTER button
e HI-POWER button
f SUPER QUIET button
g FAN CONTROL button
h ECONOMY button
i SWING button
j AIR DIRECTION (Left-Right) button
k AIR DIRECTION (Up-Down) button
l ON TIMER button
m OFF TIMER button
n SET TIME buttons (
/ )
o SET (TIMER) button
p CANCEL (TIMER) button
q TEST RUN button
r RESET button
s CLOCK ADJUST button
