System upgrades
Installing and removing the hard disk drive
Removing a hard disk drive
► Open the casing (see "Opening the casing").
► Fold up the drive cage (see "
Opening the drive cage").
1
2
1
► Slightly press together the EasyChange rails mounted on the hard disk (1) and pull the hard
disk drive out of the drive cage in the direction of the arrow (2).
► Disconnect all cables connected to the drive (data cable, power supply cable).
► Pull the EasyChange rails off the hard disk
drive.
It may be necessary to modify the entry for the drive in the
BIOS Setup.
i
► Fold down the drive cage (see "Closing the drive cage").
Fujitsu Technology Solutions 49
