D2619 (RX/TX300 S5) Technical Manual 25
Features Screen resolution
3.4 Screen resolution
Depending on the operating system used the screen resolutions in the following
table refer to the graphic controller on the system board. The graphic controller
is integrated in the iRMC (integrated Remote Management Controller).
If you are using an external graphic controller, you will find details of supported
screen resolutions in the documentation supplied with the graphic controller.
3.5 Temperature/system monitoring
Temperature and system monitoring aim to reliably protect the computer
hardware against damage caused by overheating. In addition, any unnecessary
noise is also prevented by reducing the fan speed, and information is provided
about the system status.
The temperature and system monitoring are controlled by the iRMC S2
(integrated Remote Management Controller).
The following functions are supported:
Temperature monitoring
Measurement of the processor and the system internal temperature by an
onboard temperature sensor, measurement of the ambient temperature by a
I
2
C temperature sensor.
Fan monitoring
The CPU, power supply unit and system fans are monitored. Fans that are no
longer available, blocked or sticky fans are detected.
Screen resolution Max. color depth Max. frequency
640 x 480 Hz 32 Bit 85 Hz
800 x 600 Hz 32 Bit 85 Hz
1024 x 768 Hz 32 Bit 75 Hz
1152 x 864 Hz 16 Bit 60 Hz
1280 x 1024 Hz 24 Bit 60 Hz
1600 x 1200 Hz 16 Bit 60 Hz
