Installing/removing th e pro cessor
English - 5
Installing/removing the proc
essor
Disconnect the system from the mains voltage before performing any of the tasks
described below. Details are co ntained in the operating manual of your system.
Technical data
• Socket LGA1156, max. 95
W
• A current list of the processors supported by this mainboard is available o n the
Internet at: "
http://ts.fujitsu.com/mainb oards".
• Depending on the proc
essor, internal graphics functions are provided on the m ainboard.
Never touch the unde
rside of the processor. Even minor soiling such as grease
from the skin can im
pair the processor’s operation or destro y the processor.
Place the processo
r in the socket with extrem e care, as the spring contacts
of the socket are v
ery delicate and must not be bent.
If one or more spri
ng contacts are b ent, on no account insert the processor a s it
may be dama ged by
doing so. Please contact the responsible ve ndor.
Fujitsu Technology Solutions 21
