TechNotes D307x-S V2.0 Page 8 of 56 www.ts.fujitsu.com/mainboards
Feature Overview D307x-S
Internal socket for USB stick
 Install your USB dongle inside
the chassis w/o danger of theft
 Avoids possible EMI issue with
external USB stick
Internal socket for USB flashdrive
 Easy integration of flashdrives for Embedded OS or memory
extension. Mainboard prepared for mechanical fastener
8 Bit GPIO Port
 Easy extension e.g. for status LEDs
 Easy SW integration via Windows API
 Pin layout compatible with D2703-S, D2963-S, D3003-S
Hardware Watchdog
 Incl. BIOS/Boot and OS supervision
 Easy SW integration via Windows API & Linux Driver
