TECHNICAL SPECIFICATIONS
Scanner type ADF (Automatic Document Feeder) / Manual feed
Scanning modes Simplex / Duplex; Colour / Greyscale / Monochrome
Image sensor type Dual colour CCDs (Charged Coupled Device)
Light source White fluorescent lamp
Scanning range Minimum 2.9” x 2.9”
Maximum 11” x 17”
Paper weight (Thickness) 13.9 to 34.0 lb.
Scanning speed
1
(Letter, Landscape, 200 dpi) 74 ppm / 148 ipm (colour
2
, greyscale
2
, or monochrome)
Paper chute capacity Max. 500 sheets (20 lb.)
Background colours Black and white (auto-switching)
Optical resolution 400 dpi
Output resolution Colour 100 / 150 / 200 / 300 / 400 dpi
Greyscale 100 / 150 / 200 / 240 / 300 / 400 dpi
Monochrome 100 / 150 / 200 / 240 / 300 / 400 dpi
Output format 24 bit (colour), 8 bit (greyscale), or 1 bit (monochrome).
AD converter 10 bit
Interface Ultra-wide SCSI
Connector shape Shield type 68-pin (pin type)
SCSI terminator Built-in
Output mode Dither / Error diffusion
Voltage or voltage range AC 100 to 120 V, +/-10%; 50/60 Hz +2% / -4%
Power Operating 200 watts or less.
Sleep mode Less than 12 watts.
Operational environment Temperature 15°C to 35°C (59°F to 95°F)
Relative humidity 20% to 80% (non-condensing)
Dimensions (W x D x H) 520 mm x 431 mm x 523 mm (20.5” x 17.0” x 20.6”)
Weight 49 kg (99 lb.)
Environmental compatibility RoHS.
Other Multi-feed detection Standard; Ultrasonic multi-feed detection sensor.
Paper counter Standard.
Image processing Auto crop, auto de-skew, auto colour detection, auto page
orientation, blank page detection.
Dropout colour Selectable dropout colour (red, green, or blue).
OPTIONS
Pre-scanning imprinter (fi-485PRFR) The imprinter option enables users to print information on
PA03296-D207 original documents for document management purposes.
Post-scanning imprinter (fi-486PRRE) While the fi-486PRFR prints information on the front of
PA03296-D201 documents prior to scanning, the fi-486PRRE prints information
of the back of the original documents after they have been
scanned. Although both the fi-486PRFR and the fi-486PRRE
may be attached to the same scanner unit, both imprinters
cannot be used simultaneously.
CONSUMABLES
ScanAid kit Up to 300,000 sheets or 1 year.
CG01000-498501 The kit includes 1 pick roller, 1 brake roller, 1 pad assembly, and
1 cleaning kit.
SERVICE OPTIONS
Post warranty maintenance coverage Provides post warranty remedial maintenance.
BUNDLED ITEMS
AC power cable, Installation guide, Adobe
®
Acrobat
®
7.0
Standard, ScandAll 21, ISIS/TWAIN drivers, Kofax VRS
®
4
Production.
WARRANTY
1 year on site.
Visit www.fujitsu.ca/warranty/scanner/ for more details.
VRS
®
4 Professional Production Included
VRS 4 Professional Production is included with every
fi-4860C2. VRS provides many advanced Imaging
functions that greatly increase overall efficiency in a
Production scanning environment.
Fast VRS Scanning Speed
74 ppm/148 ipm @200 dpi, Letter, Landscape in B/W,
Greyscale and Colour is achieved with VRS.
Excellent Paper Handling
13.9 to 34 lb paper is supported through the automatic
feeder.
Ultra-sonic Multi-Feed Detection
Ultra-sonic multi-feed detection is the most advanced
method for detecting multi-feeds. It works reliably even
when scanning pages of different sizes, thicknesses
and colours.
Auto Switching Background
Allows the software or scanner to switch between a
white and black background. A black background
is required for accurate auto-crop and auto deskew.
A white background is required to perform optical
system checks and re-calibrations which contribute to
consistent image quality.
Imprinter Option
The imprinter option prints a string of alphanumeric
text onto the back side of the page after scanning.
This text can include a page counter, date and time,
file number or any other alphanumeric information.
1) Actual scanning speeds are affected by data transmission and software processing times.
2) Using JPEG compression.
Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited. Adobe, Acrobat, Adobe PDF logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United
States and/or other countries. Kofax, VirtualReScan, Adrenaline and the “VRS VirtualReScan” logo are registered trademarks of Kofax Image Products. All the other trademarks mentioned herein are the
property of their respective owners. Specifications are subject to change without notice.
© 2006 Fujitsu Canada, Inc. All rights reserved. FCI-12.04.2006-E
