10. Electrical characteristics
Model name AOHG18LBCB AOHG24LBCB
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current *1 A 13.5 15.7
Starting current A 7.4 9.9
Wiring
spec. *2
Circuit breaker current A 20
Power cable
mm
2
2.5
Connection cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 26 31
*1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
*2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*3: Limit voltage drop to less than 2%. If voltage drop is 2% or more, increase cable conductor size.
