6
LifeBook S Series Notebook BIOS
Primary Master Submenu of the Main Menu
The Primary Master submenu identifies what ATA
devices are installed.
Note that actual hard drive label shown may vary.
Depending on the drive type, information such as cylin-
ders, heads and sectors may also be displayed.
Figure 2. Primary Master Submenu
Menu Field Options Default Description
Type:
■
Auto
■
None
[Auto] Select Auto to have the type of Serial or Parallel ATA device auto-
matically identified by the BIOS at POST. If None is selected, the fol-
lowing Set-up items do not appear.
LBA Format Logical Block Addressing (LBA)
Total Sectors:
---
--- The total number of sectors on your hard disk
Maximum
Capacity:
---
--- The maximum capacity of your hard disk
Multi-Sector
Transfers:
■
Disabled
■
2 Sectors
■
4 Sectors
■
8 Sectors
■
16 Sectors
[16 Sectors] This option cannot be changed when Auto is selected.
LBA Mode Control:
■
Disabled
■
Enabled
[Enabled] Enables or disables logical Block Addressing in place of Cylinder,
Head, Sector addressing. This option cannot be changed when Auto
is selected.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Main
Item Specific Help
Select ATA/ATAPI drive
installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
[None]
The drive is disabled.
Primary Master [TOSHIBA MK4025GAS-(PM)]
Type: [Auto]
LBA Format
Total Sectors: 78140160
Maximum Capacity: 40008MB
Multi-Sector Transfers: [16 Sectors]
LBA Mode Control: [Enabled]
Transfer Mode: [Multiword DMA 2]
Ultra DMA Mode: [Disabled]
▲
To Next Page
