Preliminary 23(30)
Prepared Document Number
Manfred Ortmann
Approved Checked Date Revision Storage
2008-05-23 PA 6.2 Mycable01
strapped to VCC by resistor RN402 so the slave address for readings is 0x73 and the slave
address for writings is 0x72.
The SiI164 support receiver and hot plug detection.
The triple 8-Bit high speed video digital-to-analog converter ( DAC ) ADV7125JSTZ240 ( U402
and U403 ) from Analog Devices convert the digital RGB666 video output signals from the LIME
to an analog video signals. Outputs from U402 are connected to DVI-I connector X400. Outputs
from U403 are connected to DVI-I connector X401.
Following table shows the assignment of pins, signals and function from the connectors X402
and X403. For X403 the index 0 has to be changed to 1.
Pin Signal Function
1 GND Ground
2 GND Ground
3 VO0_B0
Digital RGB output 0 Data blue
4 VO0_B1
Digital RGB output 1 Data blue
5 VO0_B2
Digital RGB output 2 Data blue
6 VO0_B3
Digital RGB output 3 Data blue
7 VO0_B4
Digital RGB output 4 Data blue
8 VO0_B5
Digital RGB output 5 Data blue
9 VO0_B6
Digital RGB output 6 Data blue
10 VO0_B7
Digital RGB output 7 Data blue
11 VO0_G0
Digital RGB output 0 Data green
12 VO0_G1
Digital RGB output 1 Data green
13 VO0_G2
Digital RGB output 2 Data green
14 VO0_G3
Digital RGB output 3 Data green
15 VO0_G4
Digital RGB output 4 Data green
16 VO0_G5
Digital RGB output 5 Data green
17 VO0_G6
Digital RGB output 6 Data green
18 VO0_G7
Digital RGB output 7 Data green
19 VCC33 + 3.3 V
20 VCC33 + 3.3 V
21 VCC33 + 3.3 V
22 VCC33 + 3.3 V
23 VO0_R0
Digital RGB output 0 Data red
24 VO0_R1
Digital RGB output 1 Data red
25 VO0_R2
Digital RGB output 2 Data red
26 VO0_R3
Digital RGB output 3 Data red
27 VO0_R4
Digital RGB output 4 Data red
