CHAPTER 4 INSTALLATION REQUIREMENTS
4.1 Mounting Requirements
4.2 Power Supply Requirements
4.3 Connection Requirements
This chapter describes the environmental, mounting, power supply, and connection requirements.
4.1 Mounting Requirements
4.1.1 External dimensions
Figures 4.1 and 4.2 show the external dimensions of the HDD and the locations of the holes for
the HDD mounting screws.
C141-E270 47
