4.3.3 Cable connector requirements
Table 4.2 lists the recommended components cable connection.
Table 4.2 Recommended components for connection
Applicable
model
Type Name
Part number
(Size)
Manufacturer
Reference
(*1)
787311-4
Tyco Electronics
AMP
NC
SCSI connector
(CN1)
Connector
71743-1085 Molex
DHJ-PAC68-2AN-
FG
Fujikura
Cable socket
(closed-end type)
5786090-7
Tyco Electronics
AMP
SCSI cable (CN1)
Signal cable
UL20528-FRX-
68-P0.635
Fujikura
S1
Cable socket housing 1-480424-0
Tyco Electronics
AMP
Contact 170148-1
Tyco Electronics
AMP
Power supply
cable (CN1)
Cable (AWG18 to 24)
S2
Cable socket housing A3B-12D-2C
HIROSE
ELECTRIC
Contact A3B-2630SCC
HIROSE
ELECTRIC
External operator
panel (CN1)
Cable (AWG26 to 36)
S3
Cable socket housing FCN-723J024/2M
FUJITSU
TAKAMIZAWA
Contact FCN-723J-G/AM
FUJITSU
TAKAMIZAWA
NP
External operator
panel (CN2)
Cable (AWG28)
S4
(*1) See Figure 4.22.
(1) SCSI cable
Refer to Section 1.3 “Physical Requirements” and Section 1.4 “Electrical Requirements” of the
SCSI Physical Interface Specifications.
(2) Power cable
HDDs must be star-connected to the DC power supply (one to one connection) to reduce the
influence of load variations.
(3) DC ground
The DC ground cable must always be connected to the HDD because no fasten tab dedicated to SG is
provided with the HDD. Therefore, when SG and FG are connected in the system, it is necessary to
connect SG and FG at the power supply or to connect SG of the power supply to FG of the system.
C141-E270 67
