E-58
MAIN SUPPORTED SIGNALS
The display can store up to four types of signals for RGB adjustment values. The display uses the first-in, first-out method; therefore, the
first input signal is cleared when the fifth one is input. Input the signal you want to store and adjust to a desired screen according to
"ADJUSTING SCREEN POSITION AND SIZE". When the adjustment has been made, it is automatically stored. Thus, when the display
receives the same signal later, pictures will be displayed in accordance with the adjustment value most recently stored.
RGB1 INPUT
• With some input signals, "Out of range" may appear or the image may appear in black and white when the horizontal and vertical
frequencies are outside their permissible ranges, or even when the frequencies are within their permissible ranges. In this case, match the
input signal to a different frequency in the above table.
In the Component Video, HDMI and Video/S-video, the display has been factory-set as follows for different input signals:
Main corresponding signals (Comp.video, HDMI mode) VIDEO1,2 INPUT (Video , S-Video mode)
RF INPUT
ANTENNA : NTSC and ATSC
CABLE : NTSC, 64QAM and 256QAM
Display (dots x lines)
Horizontal frequency (kHz)
Vertical frequency (Hz) Signal
640 x 480 31.47 59.94 VGA
640 x 480 37.50 75.00 VGA 75 Hz
640 x 480 43.27 85.01 VGA 85 Hz
720 x 400 31.47 70.09 400 lines
800 x 600 37.88 60.32 SVGA 60 Hz
800 x 600 46.88 75.00 SVGA 75 Hz
800 x 600 53.67 85.06 SVGA 85 Hz
1024 x 768 48.36 60.00 XGA 60 Hz
1024 x 768 60.02 75.03 XGA 75 Hz
1024 x 768 68.68 84.99 XGA 85 Hz
1280 x 1024 63.98 60.02 SXGA 60 Hz
1280 x 1024 79.98 75.03 SXGA 75 Hz
848 x 480 31.02 60.00
852 x 480 31.72 59.97
1360 x 768 47.71 60.01
720 x 485 15.73 59.94 60 fields
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Signal
Comp.
Video
HDMI
Horizontal
frequency (kHz)
Vertical
frequency (Hz)
Signal
15.73 59.94 480i (SD signal) 15.73 59.94 NTSC
31.47 59.94 480p (SD signal)
45.00 60.00 720p (HD signal)
33.75 60.00 1080i (HD signal)
67.50 60.00 1080p (HD signal) -
Note
• Depending on the input signal, the display may show pictures of reduced size due to size reduction and interpolation.
• You can check input signals through "Information" on the FEATURES Menu screen. (See P. E-39)
• All terms (i.e., company and product names) used in this document are trademarks or registered trademarks.
