Fujitsu PRIMEQUEST 2800B3 User Manual

CHAPTER 2 Hardware Configuration
2.15 Power Supply Unit (PSU)
73
CA92344-0534-07
FIGURE 2.38 External view of the PSU
Number
Description
(1)
Top
(2)
Front
(3)
Front perspective
(4) Right lateral
Remarks
Different PSUs (PSU_P, PSU_S) cannot be mounted in the same cabinet.
For the configuration of the PSU, see ‘4.5.1 PSU Configuration’.
2.15.1 PSU_P specifications
The specifications of PSU_P are listed in the table below.
TABLE 2.26 PSU_P Specifications
Item Specifications
Input voltage
1 φ AC 100 V-120V, 1 φAC200 V-240 V
Output voltage DC12V
Output power
AC100 V (*1) 1165 W
AC200 V 2685 W
External dimensions (mm)
(Excluding protrusions)
Width 137

Depth 255

Height 128
Weight (kg) 4.5
*1: AC 100V is not supported in the PSU_P.

Fujitsu PRIMEQUEST 2800B3 Specifications

General

Processor	Intel Xeon E7-8800/4800/2800 v2 series
Number of CPUs	Up to 4
Chipset	Intel C602J
Memory	Up to 6 TB
Memory Slots	24 DIMM slots
Storage	Up to 12 x 3.5" or 24 x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Expansion Slots	Up to 8 PCIe 3.0 slots
Power Supply	Redundant power supplies
Form Factor	4U rackmount
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
