Fujitsu PRIMERGY CX2550 M1 - Page 16

16 Operating Manual CX2550 M1
Functional overview
Onboard or integrated controllers
RAID controllers (expansion cards)
Slots
Drives
LAN controller Intel
®
Ethernet Controller I350, 2 x 10/100/1000
Mbit/s Ethernet (TCP/IP acceleration)
Remote Management
Controller
iRMC S4 (integrated Remote Management
Controller), IPMI 2.0 compatible
SATA Controller Intel
®
C610, for up to 6 x SATA HDDs/SSDs
SW Raid 0/1
RAID controllers – RAID Ctrl., SAS/SATA 12 Gbit/s, Fujitsu PRAID
CP400i, 8 ports int.
RAID level: 0, 1, 1E, 10, 5, No BBU support
– RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP420i, 8 ports int. RAID level: 0, 1, 10,
5, 50, 6, 60, 2 GB
– RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP400i, 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional
FBU based on LSI SAS3108
PCI-Express 3.0 x 16 2 x for low profile via riser card
Hard disk bays 6 x 2.5-inch
