Operating Panel
Dimensions / Weight
Ambient conditions
Condensation during operation must be avoided!
Operating buttons ID button
On/Off button
Operating LEDs On/Off (green)
System status (orange)
LAN speed (green / yellow)
LAN connection (green)
Identification (blue)
Rack (W x D x H) 1 HU half wide (175.5 mm x 520 mm x 40.8 mm)
Weight 4 kg (full populated incl. PCI expansion cards)
SKD: 2 kg
Weight notes actual weight may vary depending on configuration
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 5°C ... 40°C (with Cool-safe
®
ATD)
10°C ... 35°C (without Cool-safe
®
ATD)
Maximum temperature depends on type of
CPU
Transport (2K2) -25 °C ... +60 °C
Humidity 10% ... 85% (non condensing)
