RAID controllers (expansion cards)
Slots
Drive bays
RAID controllers RAID 5/6 Ctrl., HDD SAS up to 12 Gbit/s, LSI, 8 ports
ext. RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB Cache,
Optional FBU (based on LSI SAS3108).
RAID 5/6 Ctrl., HDD SAS up to 12 Gbit/s, 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 2 GB Cache,
Optional FBU (based on LSI SAS3108).
RAID 0/1 Ctrl., SAS/SATA 6 Gb, 8 ports int. RAID
level: 0, 1, 10, No FBU support.
PCI-Express 3.0 x8 2 x low profile
PCI-Express 3.0 x16 2x low profile (2nd processor required for slot 4)
Slot notes One PCIe Gen3 x8 slot may be occupied with a
Modular RAID controller if configured.
Hard disk bay
configuration
4, 8, 10 x 2.5-inch or 4 x 3.5-inch
Accessible drive bays 1 x 5.25/0.5-inch for DVD/RW-Blu-ray (for base-units
4, 8 x 2.5-inch HDD and 4 x 3.5-inch)
Notes accessible drives all possible options described in relevant system
configurator
