24 Operating Manual
RX2530 M4
RAID controllers (expansion cards)
Slots
Drive bays
RAID controllers Modular RAID 0/1 controller with "MegaRAID
functionality" (integrated MegaRAID).
RAID levels 0, 1, 10, 5 and 50 are supported for
internal HDD configurations.
Modular RAID 5/6 controller with "MegaRAID
functionality" (integrated MegaRAID).
RAID levels 0, 1, 10, 5, 50, 6 and 60 are supported for
internal HDD configurations. As an option, a flash
backup unit (FBU) can save the memory content even
if the power fails. Cache memory size of up to 8GB are
available.
PCI-Express 3.0 x8 1x low profile
PCI-Express 3.0 x16 3x low profile (2nd CPU required for slot 4)
Slot notes One PCIe Gen3 x8 slot may be occupied with a
Modular RAID controller if configured.
Hard disk bay
configuration
4x, 8x, 10x 2.5-inch or 4x 3.5-inch
Accessible drive bays 1x 5.25/0.5-inch for DVD/RW-Blu-ray (not for 10 HDD
variant)
Notes accessible
drives
all possible options described in relevant system
configurator
