RX2530 M4
Operating Manual 27
Electrical values of the AC PSU
Electrical values of the DC PSU
Electrical values of the Fujitsu battery unit (FJBU)
Rated voltage range 100 V to 240 V (Platinum)
200 V to 240 V (Titanium)
Frequency 50 Hz - 60 Hz
Rated current with min. configuration 4.5 A / 2.0 A
Max. rated current 10.5 A / 5.0 A
Effective power 883 W
Apparent power 892 VA
Heat dissipation 3179 KJ/h (3013 BTU/h)
Main power fuse 16 A
Protection class I
Rated voltage -48 V
Frequency DC
Max. rated current 20 A
Effective power 800 W
Main power fuse 16 A
Max. output 380 W
Backup duration Max. 2 seconds (380W), 4 minutes (280W) with
FJBU M2
Charge duration 4 hours to 90%, 5 hours to 100%
Battery spec. Nickel Metal-Hydrite battery
Battery life time 5 years
Input/Output voltage 12 V DC
Weight 1.2 kg
