TX100 S3 Operating Manual 21
Functional overview
Onboard or integrated controllers
Slots
Drive bays
Operating Panel
Serial ATA total 6
RAID Controller 4 port SATA with RAID 0 / 1 for HDDs
SATA Controller Intel
®
C202
LAN Controller Intel
®
82574L and Intel
®
82579LM onboard, 2 x
10/100/1000 Mbit/s, PXE-Boot by LAN via PXE-
Server, Teaming supported
Trusted Platform
Module (TPM)
Infineon / 1.2 (option)
PCI-Express Gen2 x1 1x (mechanically x4)
PCI-Express Gen2 x4 1x (mechanically x4)
PCI-Express Gen2 x8 1x
PCI-Express Gen2 x8 1x (mechanically x16)
Hard disk bay
configuration
4x 3,5-inch easy change SATA
Accessible drives 2 (one bay is occupied by DVD/DVD-RW, 5.25-inch)
Operating buttons On/off switch
Status LEDs Power (green)
