Fujitsu R407C User Manual

ERROR
CONTENTS
00
No errors
CAUSE
COUNTERMEASURE
1. Effect of extraneous noise.
1. Effect of extraneous noise
1. Effect of extraneouse noise
02
PC board error
( Transmission
adapter )
Memory error
2. Control panel PC board is
faulty.
03
04
CENTRAL REMOTE CONTROLLER TROUBLESHOOTING
Printed circuit
board error
(Control panel)
1. Error occurence condition
Error occurs at control
panel printed circuit board
and central remote controller
cannot be operated.
2. Relevant operation
Error display.Only error code
display is operated.
Other operations are
ineffective.
3. Clearance 
Error is cleared and central
remote controller bcomes
operable again.
2. Conrol panel printed circuit
board is faulty.
1. After ACL key is pressed, or power
is turned on again:
1) If error dosen't occur, printed circuit
board is normal. Then, remove
noise sources near operation panel.
2) If error occurs again, remove noise
sources and take measure with
the following countermeasure No.2.
1. Error occurence condition
Error occurs at transmission
adaptor control printed
circuit board and central
remote controller cannot be
operated.
2. Relevant operation
Error display.Only error
code display operation can
be paformed.Other
operations are ineffective.
3. Clearance 
Error is cleared and central
controller bcomes operable
again.
2. Transmission adaptor conrol
printed circuit board is faulty.
1. After reset key on transmission
adaptor control printed circuit board is
pressed, or power is turned on again:
1) If error doesn't occur,printed circuit
board is normal. Then, remove
noise sources near transmission
adaptor.
2) If error occurs again, remove noise
sources and take measure with
the following countermeasure No.2.
1. Error occurrence condition
Control panel momory is
failed, or model infomation
and remote controller group
registration, which are
stored in memory is failed
2. Relevant operation
1) Error occurs in normal
state.
Error and error code are
displayed . Only pressing
key SW42 on control panel
printed circuit boad is
effective. Other operations
are ineffective.
2) When error occurs in
initialize menu mode.
Error and error code
display.
Only pressing SET key is
effective. Other operations
are ineffective.
1. Initialize the setting again, after initial
setting.
1) If error doesn't occur, printed circuit
board is normal. Then, remove noise
sources near operation panel.
2) If error occurs again, remove noise
sources and take measurre with the
following countermeasure NO.2.
2. Replace control panel printed circuit
board.
3. Clearances
1) If error occurs in normal condition,
Key SW42 on control panel printed
circuit board is pressed and the
memory is cleared.
2) If error occurs on the initial setting
menu mode. Set key is pressed and
the memory is cleared.
ERROR
CODE
2. Replace transmission adaptor control
printed circuit board.
2. Replace operation panel printed
circuit board.
05-28
