ERROR
CONTENTS
1. Error occurrence condition
Control panel printed circuit
board isn't initialized
normally.
2. Relevant operation
Error display. Only error
display operation can be
performed. Other operations
are ineffective.
3. Clearance
Operation panel printed
circuit board initialization
operation is performed
normally.
CAUSE
COUNTERMEASURE
1. Effect of extraneous noise
1. After ACL key is pressed or power is
turned on again :
1) If error doesn't occur, printed circuit
board is normal. Then, remove noise
sources near operation panel.
2) If error occurs again, remove noise
sources and take measure with the
following coutermeasure No.2.
2. Printed circuit board is
faulty.
2. Replace printed circuit boards with
following procedure and confirm the
operation.
1 Replace Transmission adapter
control printed circuit board.
2 Replace Transmisson adapter
communication printed circuit board.
3 Operation panel printed cicuit board.
1. Error occurrence condition
Communication between
transmission adapter
control printed circuit board
and transmission adapter
communication printed
circuit board is not
performed normally.
2. Relevant operation
1) Error indication. Central
Remote operation is
available.
2) If error is kept to detect for
a while after error occurs,
transmission error (1F) is
output.
3. Clearance
The communication
between the control printed
circuit board and
communication printed
circuit board of transmission
adaptor is performed
correctly.
1. Effect of extraneous noise
1. After RESET key on control printed
circuit board of transmission adapter
is pressed, or power is turned on
again :
1) If error doesn't occur, printed circuit
board is normal. Then, remove noise
sources near transmission adaptor.
2) If error occurs again, remove noise
sources and take measure
with the following countermeasure
No.2,3.
Node setting
error
Parallel
communication
error
2. Transmission adapter
communication printed
circuit board insertion is
faulty.
05
06
3. Printed circuit board is
faulty.
3. Replace printed circuit boards with
following procedure and confirm
the operation.
1 Replace Transmission adapter
communication board.
2 Replace Transmission adapter control
board.
2. Check insertion for the communication
printed circuit board of transmission
adapter.
ERROR
CODE
05-29
