Fujitsu R407C User Manual

02-15
ROTARY SWITCH SETTING
EXTERNAL INPUT AND OUTPUT
Indoor unit address switch
Sets the indoor unit addresses.
INDOOR UNIT ADDRESS SWITCH
Refrigerant circuit address switch
Sets the refrigerant circuit.
REFRIGERANT CIRCUIT ADDRESS SWITCH (Factory setting SW 8: 0 SW 9: 0)
Remote controller address switch
REMOTE CONTROLLER ADDRESS SWITCH (Factory setting : 0)
When the indoor unit is wired by remote controller group, to identity the indoor unit in the remote
controller group, the number (remote controller address) in the remote controller group is set.
Set the remote controller address in the 0.1.2,~,15 order (Blank is not allowed)
1.SW6 setting
2.SW7 setting forbidden
Rotary SW7 0
Rotary SW
6
Description Remarks
Indoor unit
address SW
Indoor unit address
( 0~15 )
Rotary SW
8
9
Description Remarks
Refrigerant circuit
address 1
Refrigerant circuit
address 2
Refrigerant circuit
address (the first digit)
Refrigerant circuit
address (the second digit)
Rotary SW
10
Description Remarks
Remote controller
address SW
Remote controller
address
3.SW8,9 setting
4.SW10 setting
(Factory setting : 0)
Connector
CN21
CN27
Input
Output
OPERATION DISPLAY
(DC12V)
Remarks
Indoor unit type
Wall mounted /
Ceiling wall types
CN22
CN23
CN24
Other types
All types
CONTROL INPUT
(OPERATION / STOP)
ERROR DISPLAY
(DC12V)
INDOOR UNIT FAN
STATUS DISPLY(DC12V)
See 2-4-1
for details
