4-5 ENERGY SAVE OPERATION
MASTER
CONTROL
FAN
CONTROL
TIMER
MODE
TEMP./DAY
SET TIME
CLOCK ADJUST
START/STOP
SET DAY OFF
ZONE ENERGY SAVE
COOL
FAN
DRY
HEAT
AUTOAUTO
CLOCK
OFF
OFF
ON
ON
C
F
NEXT DAY
DAY
TIMER
NON STOP
OFFON
TIMER
WEEKLY
ANTI FREEZE
CENTRAL
DAY OFF
DEFROST TEST
12
(3) To Stop the ENERGY SAVE
Press the ENERGY SAVE button one more time.
The ENERGY SAVE mode will be turned off.
The ENERGY SAVE light goes off, and the unit will return to the former operat-
ing conditions.
(2) To Use the ENERGY SAVE
Press the ENERGY SAVE button.
The unit will run in the ENERGY SAVE mode.
(1) About the ENERGY SAVE
The energy conservation mode (ENERGY SAVE) raises the set temperature slightly in the cooling mode and lowers the set
temperature in the heating mode, using a computer program to economically control the operation of the unit.
If you press the ENERGY SAVE button while the air conditioner is on , it will change to the conservation mode. if you press
the ENERGY SAVE button while the unit is in the timer mode (ON timer or WEEKLY timer), the unit will go into
the conservation mode when the unit starts with the timer.
If you turn off the air conditioner while in the conservation mode, the mode will be shut off.
When Heating
After the ENERGY SAVE button is pressed, the set tempera-
ture will be lowered about 1 C every 30 minutes. When it
has lowered a total of 4 C, than it will hold that tempera-
ture.
When Cooling
After the ENERGY SAVE button is pressed, the set tempera-
ture will be raised about 0.5 C every 30 minutes. When it
has gone up a total of 1 C, then it will hold that tempera-
ture.
30 min.
0.5 C
1 C
Set to the ENERGY SAVE mode.
1 C
2 C
30 min.

Set to the ENERGY SAVE mode.
60 min.
90 min.
3 C
4 C
