Fujitsu ScanSnap S1300 Installation & Troubleshooting Guide

When ScanSnap Manager does not operate normally
27
5. Check the privileges to access the installation files.
1. Select [Start] menu  [All Programs]  [ScanSnap Manager]  [ScanSnap Support
Tool].
 The [ScanSnap Support Tool] dialog box appears.
2. Click the [Check] button, and proceed by following the instructions displayed on the
screen.
 If the message "The recommended privileges have been applied." appears, turn
the ScanSnap off then back on. Make sure to leave at least five seconds between
turning the power ON/OFF.
6. Close the ADF paper chute (cover), and restart your computer.
If the message "Failed to change the privileges. Uninstall ScanSnap Manager then install it again."
appears or the problem still persists, proceed to step 6.

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
