Front of the MU Management Unit
50 U41858-J-Z126-2-76
6.1 Front of the MU
Figure 8: Management Unit (MU) - front of a MU M1
Figure 9: Management Unit (MU) - front of a MU M2
Indicators on the front panel of MU M1
Figure 10: MU M1 (front panel)
1 HDD fault indicator 10 HDD activity indicator
2 Power supply fault indicator 11 Status indicator
3 Temperature fault indicator 12 On/Off button
4 CPU fault indicator (notify Customer Support) 13 NMI button (for Customer Support only)
To Next Page
