3
1
Name and Shape
Q’ty
Application
Remote control unit
Battery (penlight)
Remote control unit
holder
Tapping screw
(ø3 x 12)
1
4
1
2
Use for air condi-
tioner operation
For remote
control unit
For mounting the
remote control
unit
For remote
control unit holder
installation
VT wire
For fixing the drain
hose L 280 mm
Name and Shape
Q’ty
Application
Hexagon wrench
1
For air purge
OUTDOOR UNIT ACCESSORIES
Name and Shape
Part No.
Application
Joint pipe-A For indoor
side pipe joint
9302812021
OPTIONAL PARTS FOR INDOOR UNIT
Name and Shape
Q’ty
Application
STANDARD PARTS
The following installation parts are furnished. Use them as required.
1
1
2
4
4
4
2
6
1
1
1
1
1
1
1
Cover plate (left)
Tapping screw
(ø4 x 10)
For positioning the
indoor unit
For under ceiling type.
Anchor bolt (M12)
Spring nut
For suspending the
indoor unit on the
wall.
Tapping screw
(ø4 x 20)
For fixing the wall
bracket.
Coupler heat insulator
(large)
For indoor side
pipe joint
(Large pipe)
Nylon fastener
For suspending
the indoor unit
from ceiling
Cover plate (right)
Bracket (left)
Spring washer
Wall bracket
Installation template
Bracket (right)
INDOOR UNIT ACCESSORIES
1
,,,
For fixing the
drain hose
Drain hose
Insulation (drain hose)
Adhesive type
70 x 230
Coupler heat insulator
(small)
For indoor side
pipe joint
(small pipe)
