2. SYSTEM OUTLINE
2-2. FEATURES
The front panel of the remote controller can be divided by function into three different control areas.
CHECK
ACL
MASTER
ENERGY ANTI
FAN
TIMER
SET
TIMER
DELETE
TIMER
DAY
CLOCK
ADJUST
DAY OFF
TEMP.
MEMORY
OPERATION
MEMORY
TEST
SET
CENTRAL
DELETE
BACK
GROUP
ZONE
ON OFF
TIME
CONTROL
CONTROL
FILTER
RESET
CONTROL
FREEZE
COPY
TIMER
MODE
SAVE
SETTING SETTING
CENTRAL CONTROL
The central control provides management of indoor units. This includes placing restrictions on the standard
remote controllers or performing memory operations.
TIMER AREA CENTRAL CONTROL AREA OPERATION AREA
TUE
SUN
MON
WEDTHU
FRI
SAT
2
3
4
5
6
7
8
If multiple remote control
groups are set as one
group,the control of these
remote control groups can be
realized by simply choosing the
group.
By setting the central remote controller,
it is possible to lock the function of the
standard controllers. Items of selections
to lock are all functions, timer mode,
operating mode, temperature setting,
reset filter, and ON/OFF.
Setting contents of central remote
controller are all memorized, so
that each indoor unit can be
operated in the memorized
condition even if the operating
conditions are changed later on.
4-1. GROUP INFORMATION STORE
4-2. STANDARD REMOTE CONTROL
OPERATION PROHIBIT SETTING
4-3. MEMORY OPERATION
OPERATION CONTROLTIMER CONTROL
When the temperature of the room becomes low,the
indoor unit will automatically start the heating operation
until the temperature increases to a preset temperature.
Weekly timer is equipped as standard
function. (Up to 2 times ON/OFF per day
for one week).
This function provides a controlled operation(such
as to stop operation)of the indoor units in the
same manner as the standard remote controller.
5-10. ANTI FREEZE OPERATION6-3. WEEKLY TIMER
This function is used to provide time-related
controls, such as start and stop, of the indoor unit
by presetting the timer.
Other basic functions
Notes: • Central remote controller can control the indoor unit by all / group / individual.
• UP to 400 indoor units or 64 group can be controlled with one central remote controller.
• UP to 16 central remote controllers can be connected in one system.
