Fujitsu UTY-RNNUM User Manual

En-3
4.2. Name of parts
With cover open ●
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Display panel
Display panel ●
16 17
18
19
20
21
22
26
24
25
23
27 28
1
“
”, “ ” (Set Temperature
Button)
2
“ ” (Timer Mode/Clock Adjust
Button)
3
“ ” (Day/Day OFF Button)
4
“
” (Set Back Button)
5
“ ”, “ ” (Set Time Button)
6
“ ” (Timer Delete Button)
7
“
” (Timer Set Button)
8
“ ” (Start/Stop Button)
9
“ ” (Mode Button)
0
“ ” (Fan Control Button)
A
“ ” (Horizontal airfl ow direction and swing Button)
B
“ ” (Vertical airfl ow direction and swing Button)
C
“ ” (Economy/Thermo Sen-
sor Button)
D
“ ” (Maintenance/Filter Reset
Button)
E
Operation Lamp
F
Day Display
G
Operation Lock Display
H
Temperature Display
I
Fan Speed Display
J
Timer Mode Display
K
Operation Mode Display
L
Timer and Clock Display
M
Filter Display
N
Economy Display
O
Thermo Sensor Display
P
Vertical Swing Display
Q
Horizontal Swing Display
R
Defrost Display
4. SELECTING AN INSTALLATION
LOCATION
4.1. Dimensions
4-3/4 (120)
4-3/4 (120)
23/32
(18)
3-9/32 (83.5)
5/8
(15.3)
2-1/2 (63.5)
Hole
1-25/32
3/16 (
4.5
)
11/32
(9)
1/2
(12.5)
(45.3)
Hole × 2
Hole × 3
3/16
(4.5)
3/16 (4.5)
1/4
(6)
1-3/16
(30)
1-5/16
(33.5)
29/32
(23)
Unit: in. (mm)
