“Weekly timer setting” screen consists of 2 pages “Time
1-4” and “Time 5-8”. You can set 4 patterns per page,
and with pressing the [Screen switch button (Left/
Right)], the screen switches between “Time 1-4” and
“Time 5-8” during the setting.
5
6
7
8
Weekly 1
Day
Time
End
Su Mo Tu Fr SaThWe
Weekly timer setting
Time 1-4
Mo 10:00
Back:
Setting:
3. Press the [Enter button]. Then select [Weekly 1] or [Weekly 2]
with the [Cursor button (Up/Down)], and press the [Enter
button].
1
2
3
4
Weekly 1
Day
Time
End
Su Mo Tu Fr
Sa
ThWe
Weekly timer setting
Time 5-8
Cancel:
Mo 10:00
OK:
4. Select applicable days of the week as follows:
(1) Select [Day] with the [Cursor button (Up/Down)] and
press the [Enter button].
1
2
3
4
Weekly 1
Day
Time
End
Su Mo Tu Fr SaTh We
Weekly timer setting
Time 5-8
Mo 10:00
Back:
Setting:
(2) Setting screen for the current day of the week opens.
1
2
3
4
Weekly 1
Day
Time
End
Su
Mo
Tu
Fr
Sa
Th
We
Weekly timer setting
Time 5-8
Mo 10:00
Cancel:
OK:
(3) Select applicable day of the week with the [Cursor
button (Left/Right)], and press the [Cursor button (Up/
Down)]. Selected day of the week is highlighted.
1
2
3
4
Weekly 1
Day
Time
End
Su Mo
Tu
Fr
Sa
Th
We
Weekly timer setting
Time 5-8
Mo 10:00
OK:
Cancel:
Only the selected days of the week are displayed when
you press the [Enter button].
1
2
3
4
Weekly 1
Day
Time
End
Su
M
o
Weekly timer setting
Time 5-8
Mo 10:00
Setting:
Back:
If you press the [Cancel button] here, the selection of
the day will be canceled.
5. Set the desired conditions on the timer, such as time set-
ting of On/Off timer, On/Off, operating mode (only for the
On timer), and temperature (only for the On timer), up to 8
patterns per selected day as follows:
(1) Select [Time] with the [Cursor button (Up/Down)] and
press the [Enter button].
1
2
3
4
Weekly 1
Day
Time
End
Su
M
o
Weekly timer setting
Time 5-8
Mo 10:00
Setting:
Back:
(2) Move the cursor between each pattern number with the
[Cursor button (Up/Down)], and press the [Cursor button
(Left/Right)] to set the time setting of On/Off timer, On/
Off, operating mode and temperature for each pattern.
1
2
3
4
Weekly 1
Day
Time
End
Su
M
o
Weekly timer setting
Time 5-8
Mo 10:00
Delete:Push
for two seconds
OK:
Notes
To delete the setting, move the cursor to the pattern
number, and press the [Cancel button] for 2 seconds.
