En-6
MODBUS
convertor
address
DIP Switch Setting
ON:
/ OFF:
SET5-1 SET5-2 SET5-3 SET5-4 SET4-1 SET4-2 SET4-3 SET4-4
163 ●○●○○○●●
164 ●○●○○●○○
165 ●○●○○●○●
166 ●○●○○●●○
167 ●○●○○●●●
168 ●○●○●○○○
169 ●○●○●○○●
170 ●○●○●○●○
171 ●○●○●○●●
172 ●○●○●●○○
173 ●○●○●●○●
174 ●○●○●●●○
175 ●○●○●●●●
176 ●○●●○○○○
177 ●○●●○○○●
178 ●○●●○○●○
179 ●○●●○○●●
180 ●○●●○●○○
181 ●○●●○●○●
182 ●○●●○●●○
183 ●○●●○●●●
184 ●○●●●○○○
185 ●○●●●○○●
186 ●○●●●○●○
187 ●○●●●○●●
188 ●○●●●●○○
189 ●○●●●●○●
190 ●○●●●●●○
191 ●○●●●●●●
192 ●●○○○○○○
193 ●●○○○○○●
194 ●●○○○○●○
195 ●●○○○○●●
196 ●●○○○●○○
197 ●●○○○●○●
198 ●●○○○●●○
199 ●●○○○●●●
200 ●●○○●○○○
201 ●●○○●○○●
202 ●●○○●○●○
203 ●●○○●○●●
204 ●●○○●●○○
205 ●●○○●●○●
206 ●●○○●●●○
207 ●●○○●●●●
208 ●●○●○○○○
209 ●●○●○○○●
210 ●●○●○○●○
211 ●●○●○○●●
212 ●●○●○●○○
213
●●○●○●○●
214 ●●○●○●●○
215 ●●○●○●●●
216 ●●○●●○○○
217 ●●○●●○○●
218 ●●○●●○●○
219 ●●○●●○●●
220 ●●○●●●○○
221 ●●○●●●○●
222 ●●○●●●●○
223 ●●○●●●●●
224 ●●●○○○○○
225 ●●●○○○○●
226 ●●●○○○●○
227 ●●●○○○●●
228 ●●●○○●○○
229 ●●●○○●○●
230 ●●●○○●●○
231 ●●●○○●●●
232 ●●●○●○○○
233 ●●●○●○○●
234 ●●●○●○●○
235 ●●●○●○●●
236 ●●●○●●○○
237 ●●●○●●○●
238 ●●●○●●●○
239 ●●●○●●●●
240 ●●●●○○○○
241 ●●●●○○○●
242 ●●●●○○●○
243 ●●●●○○●●
244 ●●●●○●○○
245 ●●●●○●○●
246 ●●●●○●●○
247 ●●●●○●●●
(
: Factory setting)
(2) MODBUS communication setting: Baud rate setting (SET6-4)
ON: 19200bps
OFF: 9600bps (Default)
(3) MODBUS communication setting: Parity setting (SET6-3)
ON: odd
OFF: even (Default)
* When the STOP bit setting is “2bit,” parity is set to “None” regardless
of the setting of this switch.
(4) MODBUS communication setting: Stop bit setting (SET6-2)
Stop bit can be set (1 bit or 2 bit).
ON: 2bit
OFF: 1bit (Default)
(5) MODBUS communication setting: MODBUS communication terminal
resistance (SET7-4)
MODBUS communication terminal resistance can be set (Valid or
invalid).
Terminal resistance: 120Ω
Set the terminal resistances as necessary.
For MODBUS system, terminal resistances are necessary at the both
ends of communication line. (Total 2 terminal resistances)
Set the terminal resistances at the both ends to be valid and set the
terminal resistances other than at the both ends to be invalid.
ON: Terminal resistance valid
OFF: Terminal resistance invalid (Default)
* The switches from (1) to (4) are read at the time of power-on. Even if
these switches are changed after power-on, the setting is not re ected.
(6) Unused SW
SET6-1, SET7-1 to 3: Not used
All Default settings: “OFF
