ON/OFF Button
This Button will turn the Laser On and Off .
When turned on, the Laser will auto self level within
15-20 seconds and start spinning a level datum.
No other button needs to be pressed for the
laser to self level.
KEY PAD OVERVIEW
7
Scan Mode
(Stop Dot, 10°, 45°, 90°, 180° Line)
Rotational Speed Control - Tortoise/
Hare. Zero (Stop Dot), 60, 300 &
600rpm
Manual Override
(Disables Self Levelling!)
Move Stop Dot / Scan Line Left
(Scan Mode Must Be Running)
Move Stop Dot / Scan Line Right
(Scan Mode Must Be Running)
Up / Down Arrows
(Grade / Slope Controls)
Right Arrow
(Grade / Slope Control)
Left Arrow
(Grade / Slope Control)
Automatic Drift System (ADS)
