LASER DETECTOR OVERVIEW
9
The FRE-203XR Kit is available with either the standard FRD600R Detector or the upgraded
FRD800R Detector with mm/inch display. The overview below shows the standard FRD600R.
125mm Reception Pick-up Window
LED Indicators
Detector Sensitivity: Fine, Medium & Course
(+/- 1mm, +/-2.5mm & +/- 5mm)
Front LCD Display Screen
FMB-02 Staff Mounting
Bracket
ON/OFF Button
Sounder (Quiet, Loud & Off )
Back Light (On / Off )
FRONT
Power Supply & Battery Replacement
● The FRD600R Detector is powered by 1 x 9v PP3 alkaline battery which will be pre-installed.
● When required, open the rear battery compartment and fi t 1 x 9v PP3 alkaline replacement
battery, taking care to ensure correct polarity.
