FUNAI 31A-250 - Waveforms

WAVEFORMS
NOTE:
Input
VCR: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL)
(WF1~WF3)
WF3
V-OUT E-E
10µs 50mV x 10
J23
WF3
UPPER
WF1
LOWER
V-OUT 0.1V x 10
RF-SW 0.5V x 10
50µs
J23
TP502
WF2
C-PB 10mV x 10
RF-SW 0.5V x 10
5ms
UPPER
LOWER
WF1
TP502
TP301
