FUNAI 31A-250 - Page 50

20060425 1-17-8 HM240EL
JACK CBA
R703 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R705 C CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
C CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R706 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R851 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002
R852 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R853 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
SWITCHES
SW501 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW502 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW503 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW504 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW505 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW506 LEAF SWITCH MXS01830MVP0 SSC0101MCE03
SW507 ROTARY MODE SWITCH SSS-53MD SSR0106KB003
SW509 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW510 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW511 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW512 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
2B7 SHIELD ASSEMBLY HG470ED 0VM416072
2B8 BUSH LED(F) H3700UD 0VM409508
2B46 ROHM HOLDER H7770JD 0VM304573
AC001! AC CORD PE8G2CG9G0A-057 WAE0172LW012
F001! FUSE T1.6AL/250V or PAGC20BW3162
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH001 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
FH002 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
J902 BEAD CORE ASSEMBLY HK47PED 1VSA12575
JW001 FLAT CABLE 7P AWG26#2651/P2.0/150 WX3807S6FF15
JW002 FLAT CABLE 8P AWG26#2651/P1.25/150 WX1HC267-001
PS503 PHOTO INTERRUPTER RPI-302C70 QPWZP1302C70
RS501 REMOTE RECEIVER MIM-93M9DKF or USESJRSUNT03
REMOTE RECEIVER PIC-37042LQ USESJRSKK038
T001! TRANS POWER 6707 LTTZPE0KT003
TP301 PCB JUMPER D0.6-P10.0 JW10.0T
TP501 PCB JUMPER D0.6-P6.0 JW6.0T
TP502 PCB JUMPER D0.6-P5.0 JW5.0T
TP506 PCB JUMPER D0.6-P5.0 JW5.0T
TP507 PCB JUMPER D0.6-P6.0 JW6.0T
TU701 A,C TUNER UNIT TMDG2-861A UTUNPLGAL014
TU701 B TUNER UNIT TMDZ2-761A UTUNPSLAL004
Ref. No. Mark Description Part No.
VR501 CARBON P.O.T. VZ067TL1 B104 PB(F) VRCB104HH014
X301 XTAL 4.433619MHz or FXC445LLN004
XTAL 1K*044334EE or FXC445LDS002
QUARTZ CRYSTAL 4.433619MHz FXC445LCHE01
X501 XTAL 12MHz 12.000MHz or FXD126LDS002
QUARTS CRYSTAL 12.000000MHz FXD126LCHE01
X502 XTAL QTF38-32768K125P20L or FXC323LQUA02
XTAL DT38 32.768kHz FX0323LDS001
Ref. No. Mark Description Part No.
JACK CBA (MCV-C)
Consists of the following:
----------
CAPACITORS
C102 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C104 CHIP CERAMIC CAP.(1608) CH J 470pF/
50V
CHD1JJ3CH471
C105 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C107 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C108 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C109 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C112 CHIP CERAMIC CAP.(1608) CH J 470pF/
50V
CHD1JJ3CH471
C113 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C115 ELECTROLYTIC CAP. 100µF/16V M H7 or CE1CMAVSL101
ALUMINUM ELECTROLYTIC CAP
100µF/16V H7
CE1CMAVSM101
C116 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C117 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
DIODES
D101 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D102 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D103 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D104 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D105 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
COILS
L101 BEAD CORE ASSEMBLY HK47PED 1VSA12574
L102 BEAD CORE ASSEMBLY HK47PED 1VSA12574
TRANSISTORS
Q101 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
Q102 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
RESISTORS
R101 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R102 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R105 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R106 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R108 CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R109 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R110 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R111 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R114 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
Ref. No. Mark Description Part No.
