FUNAI DRV-C3835 - Page 73

20050417 1-19-5 E9B00EL
C1560 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1563 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTM101
C1564 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1565 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101
C1566 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1567 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V M
CE1CMASTM470
C1569 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1572 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1573 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1576 CHIP CERAMIC CAP.(1608) CH J 270pF/
50V
CHD1JJ3CH271
C1577 CHIP CERAMIC CAP.(1608) CH J 270pF/
50V
CHD1JJ3CH271
C1578 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1580 ELECTROLYTIC CAP. 22µF/16V M or CE1CMASDL220
ALUMINUM ELECTROLYTIC CAP 22µF/
16V M
CE1CMASTM220
C1581 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1585 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101
C1586 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1588 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1590 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1591 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1592 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1594 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1595 ELECTROLYTIC CAP. 22µF/16V M H7 or CE1CMAVSL220
CAP ELE H7-85 22µF/16V H7 CE1CMAVSM220
C1597 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1598 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C1599 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1601 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C1602 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C1605 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1606 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1607 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1609 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
Ref. No. Mark Description Part No.
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1612 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP
100µF/6.3V H7
CE0KMAVSM101
C1617 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C1618 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C1619 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1620 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1621 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ALUMINUM ELECTROLYTIC CAP 10µF/
50V M
CE1JMASTM100
C1623 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1626 CHIP CERAMIC CAP. F Z 0.22µF/16V CHD1CZ30F224
C1627 CHIP CERAMIC CAP. F Z 0.22µF/16V CHD1CZ30F224
C1628 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1629 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1630 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1631 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1632 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1633 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1634 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1635 ELECTROLYTIC CAP. 0.33µF/50V M or CE1JMASDLR33
ALUMINUM ELECTROLYTIC CAP
0.33µF/50V M
CE1JMASTMR33
C1636 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101
C1637 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1639 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1640 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1643 ELECTROLYTIC CAP. 47µF/6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASTM470
C1646 ELECTROLYTIC CAP. 22µF/16V M or CE1CMASDL220
ALUMINUM ELECTROLYTIC CAP 22µF/
16V M
CE1CMASTM220
C1648 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1649 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1652 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1657 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1658 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1659 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1660 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1661 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1662 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C1663 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
Ref. No. Mark Description Part No.
