FUNAI LC320SLX - Mechanical Parts List

20090203 14-1 A91F3CA
MECHANICAL PARTS LIST
[ LC320SLX (Serial No. : DS1A**********) ]
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
STAND ASSEMBLY A91F1UH 1ESA19883
A1 FRONT CABINET A91F3UH 1EM023528
A2 CONTROL PLATE A91F3UH 1EM325778
A5 DECORATION PLATE A91F3UH 1EM123373
A6 REAR CABINET A91F0UH 1EM023565
A8 AC CORD HOLDER A94F0UH 1EM325557
A10# RATING LABEL A91F3UH ----------
A11 JACK LABEL A91F0UH 1EM428377
A13 JACK HOLDER A94F0UH 1EM123173
A15 LOGO LABEL A8A71UH ----------
B1 SHIELD BOX A94F0UH 1EM222764
B4 STAND HOLDER 32W A94F0UH 1EM222763
B5 WALL MOUNT BRACKET A84N0UH 1EM323797
B8 SPEAKER HOLDER (L) A94F0UH 1EM123233
B9 SPEAKER HOLDER (R) A94F0UH 1EM123234
B15 CLOTH(10X180XT0.5) L0336JG 0EM408827
B27 GASKET A8AF0UH 1EM425861
CL201 WIRE ASSEMBLY 15PIN FFC 15PIN 140MM WX1A94F0-104
CL801 WIRE ASSEMBLY 2PIN 2PIN 310MM RED
BLACK
WX1A94F0-202
CL802 WIRE ASSEMBLY 2PIN 2PIN 100MM RED
BLACK
WX1A94F0-203
CL1003 WIRE ASSEMBLY 11PIN FFC 11PIN 110MM WX1A94F0-105
CL3701 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL3702 WIRE ASSEMBLY 29PIN FFC 29PIN 70MM WX1A94F0-111
CL3902 WIRE ASSEMBLY 24PIN FFC 24PIN 80MM WX1A94F0-106
L1 SCREW P-TIGHT M4X14 BIND HEAD+BLK GBHP4140
L2 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L6 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L7 DOUBLE SEMS SCREW M4X10 + BLK FPH34100
L8 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392A
L9 STAND SCREW KIT A91F0UH 1ESA19881
LCD1 LCD MODULE CMO 6BIT A GRADE UH32MXA
SP801 SPEAKER MAGNETIC S0412F06A DSD0809XQ006
SP802 SPEAKER MAGNETIC S0412F06A DSD0809XQ006
PACKI NG
S1 CARTON A91F3UH 1EM428077
S2 STYROFOAM TOP A91F0UH 1EM023566
S3 STYROFOAM BOTTOM A91F0UH 1EM023567
S4 SET BAG (900X850) A8AFFUH 1EM324904
S5 SERIAL NO. LABEL TD812HC ----------
S6 STAND BAG A94F0UH 1EM428757
S9 STAND HOLD PAD A94F1UH 1EM023746
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A91F3UH 1EMN24299
X3 REMOTE CONTROL NH000UD NF000UD NH000UD
X4 DRY BATTERY R03/2S XB0M451T0006
X6 QUICK START GUIDE A91F3UH 1EMN24639
X8 CHILD SAFETY SHEET A94F1UH 1EMN24522
X10 REGISTRATION CARD (SYLVANIA) A94F1UH 1EMN24700
Ref. No. Description Part No.
