MECHANICAL PARTS LIST [ 32MF369B/F7 ]
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
STAND ASSEMBLY A91F0UH 1ESA19880
A1 FRONT CABINET A91FTUH 1EM024665
A2 CONTROL PLATE A91F0UH 1EM325799
A5 DECORATION PLATE A91FTUH 1EM123993
A6 REAR CABINET A91FSUH 1EM024386
A8 AC CORD HOLDER A94F0UH 1EM325557
A10# RATING LABEL A91FTUH ----------
A11 JACK LABEL A91F0UH 1EM428377
A12 POP LABEL A91FTUH ----------
A13 JACK HOLDER A91FSUH 1EM123833
B1 SHIELD BOX A91FSUH 1EM123853
B4 STAND HOLDER 32W A91FSUH 1EM223483
B5 WALL MOUNT BRACKET A84N0UH 1EM323797
B8 SPEAKER HOLDER (L) A94F0UH 1EM123233
B9 SPEAKER HOLDER (R) A94F0UH 1EM123234
B15 CLOTH(10X180XT0.5) L0336JG 0EM408827
B27 GASKET A8AF0UH 1EM425861
B29 GASKET(10X50XT2) A91FSUH 1EM430237
B39 PCB HOLDER A91FSUH 1EM024387
B40 STAND HOLDER BRACKET A91FSUH 1EM223484
B41 STAND RUBBER FOOT A94N0UH 1EM428126
B42 GASKET A71F0UH 1EM424393
CL201 WIRE ASSEMBLY 5PIN FFC 5PIN 80MM WX1A91FS-104
CL801 WIRE ASSEMBLY 2PIN 2PIN 260MM RED
BLACK
WX1A91FS-202
CL802 WIRE ASSEMBLY 2PIN 2PIN 190MM RED
BLACK
WX1A91FS-203
CL3701 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL3702 WIRA ASSEMBLY 29PIN FFC 29PIN 70MM WX1A94F0-111
CL3901 WIRE ASSEMBLY 30P-31P 30PIN-31PIN/
350MM
WX1A91FS-301
L1 SCREW P-TIGHT M4X14 BIND HEAD+BLK GBHP4140
L2 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L6 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L7 DOUBLE SEMS SCREW M4X10 + BLK FPH34100
L8 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392B
L9 STAND SCREW KIT A91F0UH 1ESA19881
L13 SCREW SEMS M4X8 PAN HEAD + FPJ34080
LCD1 LCD MODULE LTA320AP01 UDULCD0SM001
SP801 SPEAKER MAGNETIC S0412F06A DSD0809XQ006
SP802 SPEAKER MAGNETIC S0412F06A DSD0809XQ006
PACKI NG
S1 CARTON A91FTUH 1EM429997
S2 STYROFOAM TOP A91FSUH 1EM024388
S3 STYROFOAM BOTTOM A91FSUH 1EM024389
S4 SET BAG A71FCUH 1EM323657
S5 SERIAL NO. LABEL TD812HC ----------
S6 STAND BAG A94F0UH 1EM428757
S9 STAND HOLD PAD A94F0UH 1EM023745
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A91F0UH 1EMN24339B
X3 REMOTE CONTROL NF802UD NF802UD
X4 DRY BATTERY R03/2S XB0M451T0006
X6 QUICK START GUIDE A91F0UH 1EMN24479
X8 CHILD SAFETY SHEET A94F0UH 1EMN24439
X10 REGISTRATION CARD (MAGNAVOX)
A94F0UH
1EMN24699
X15 HDMI CABLE HIGH SPEED 1500/BLACK WPZ152JVE001
Ref. No. Description Part No.
