20091009 15-5 A91F3EL
JACK CBA(MPW-2)
INVERTER ASSEMBLY
INVERTER CBA
R891 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R892 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R893 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
MISCELLANEOUS
AC601# AC CORD W/O A GND WIRE UL/CSA 1770 NO
BLACK
WAC0172LW022
B11 POW HEAT SINK A7120UH 1EM423993
B12 MODULE HEAT SINK PMC P7150UT 1EM423968
BC301 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC801 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC802 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC803 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC804 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC805 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC841 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
CL701 WIRE ASSEMBLY 9P 9PIN/170MM WX1A94F0-002
F601# FUSE STC4A125V U/CT PAGE20CW3402
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
JK721 JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK722 JACK RCA PCB S RED 01/RCA-101H(RD) JXRJ010YUQ01
JK731 JACK RCA PCB S GREEN 01/RCA-101H(GN) JXRJ010YUQ03
JK732 JACK RCA PCB S BLUE 01/RCA-101H(BL) JXRJ010YUQ04
JK733 JACK RCA PCB S RED 01/RCA-101H(RD) JXRJ010YUQ01
JK741 JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK742 JACK SW RCA PCB S RED RCA-102H(RD) JYRJ010YUQ03
JK841 JACK RCA PCB S ORANGE 01/RCA-101H(OR) JXRJ010YUQ06
JK871 JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK872 JACK RCA PCB S RED 01/RCA-101H(RD) JXRJ010YUQ01
JS202 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
JS301 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
JS304 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
L3 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
T601# TRANS POWER BCK-28-9932 LTT2PC0XB043
TM601 EYELET TYPE D-1 0VM406868
TM602 EYELET TYPE D-1 0VM406868
TU301 TUNER UNIT ATSC/NTSC/QAM UC020AF UTUNNTUSP035
Ref. No. Description Part No.
JACK CBA(MPW-2)
Consists of the following:
----------
CAPACITORS
C754 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C755 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C756 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C757 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
C758 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
RESISTORS
R751 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R752 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R753 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R756 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R757 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R758 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R759 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R760 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R761 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R762 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
MISCELLANEOUS
Ref. No. Description Part No.
JK751 JACK SW DIN PCB L DIN-435C(777D) JYEL040YUQ03
JK752 JACK RCA PCB L RCA-101S(1)-03 JXRL010YUQ12
JK753 JACK RCA PCB L RCA-101S(1)-04 JXRL010YUQ13
JK754 JACK SW RCA PCB L RCA-102F(RD) JYRL010YUQ05
Ref. No. Description Part No.
INVERTER ASSEMBLY
Consists of the following:
A91F0M1V-001
INVERTER CBA
---------------------------------------------------------------------
FUNCTION CBA
IR SENSOR CBA
JUNCTION CBA
A91F0M1V-001-IV
----------------------------
A91F0M1V-001-FNIRJN
Ref. No. Description Part No.
INVERTER CBA
Consists of the following:
----------
CAPACITORS
C1001 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1002 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1003 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1004 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1005 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1006 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1007 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1008 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1009 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C1011 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1012 POLYESTER FILM CAP. (PB FREE) 0.0039µF/
100V J
CA2A392DT018
C1013 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1014 CHIP CERAMIC CAP.(1608) B K 6800pF/50V CHD1JK30B682
C1040 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C1052 ELECTROLYTIC CAP 100µF/100V CE2AMZNDL101
C1053 ELECTROLYTIC CAP 100µF/100V CE2AMZNDL101
C1056 ELECTROLYTIC CAP 100µF/100V CE2AMZNDL101
C1061 CAP CERAMIC HV 15pF/6KV/SL/J CCA1500TE009
C1062 CAP CERAMIC (AX) 1500pF/50V/B/K CA1J152TU061
C1063 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1064 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1065 CAP CERAMIC HV 15pF/6KV/SL/J CCA1500TE009
C1066 CAP CERAMIC (AX) 1500pF/50V/B/K CA1J152TU061
C1067 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1068 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1072 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1111 CAP CERAMIC HV 15pF/6KV/SL/J CCA1500TE009
C1112 CAP CERAMIC (AX) 1500pF/50V/B/K CA1J152TU061
C1113 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1114 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1115 CAP CERAMIC HV 15pF/6KV/SL/J CCA1500TE009
C1116 CAP CERAMIC (AX) 1500pF/50V/B/K CA1J152TU061
C1117 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1118 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1122 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1161 CAP CERAMIC HV 15pF/6KV/SL/J CCA1500TE009
C1162 CAP CERAMIC (AX) 1500pF/50V/B/K CA1J152TU061
C1163 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1164 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1165 CAP CERAMIC HV 15pF/6KV/SL/J CCA1500TE009
C1166 CAP CERAMIC (AX) 1500pF/50V/B/K CA1J152TU061
Ref. No. Description Part No.
