20091009 15-17 A91F8EL
FUNCTION CBA
R1168 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1169 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1170 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1171 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1172 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1210 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1211 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1212 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1213 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1214 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1215 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1216 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1217 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1218 CHIP RES. 1/10W J 390 Ω RRXAJR5Z0391
R1219 CHIP RES. 1/10W F 18k Ω RRXAFR5H1802
R1220 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1221 RES CARBON FILM T 1/4W J 27k Ω RCX4273T1001
R1222 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1500 CHIP RES. 1/10W J 12k Ω RRXAJR5Z0123
R1501 RES CARBON FILM T 1/4W J 10 Ω RCX4100T1001
R1502 RES CARBON FILM T 1/4W J 150 Ω RCX4151T1001
R1503 RES CARBON FILM T 1/4W J 2.2k Ω RCX4222T1001
R1504 RES CARBON FILM T 1/4W J 2.2k Ω RCX4222T1001
R1505 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1506 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1550 RES CARBON FILM T 1/4W J 12k Ω RCX4123T1001
R1551 RES CARBON FILM T 1/4W J 10 Ω RCX4100T1001
R1552 RES CARBON FILM T 1/4W J 150 Ω RCX4151T1001
R1553 RES CARBON FILM T 1/4W J 2.2k Ω RCX4222T1001
R1554 RES CARBON FILM T 1/4W J 2.2k Ω RCX4222T1001
R1555 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1556 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1600 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R1601 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1620 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1621 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1630 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1631 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R1700 CHIP RES. 1/10W J 8.2k Ω RRXAJR5Z0822
R1701 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1800 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1801 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R1802 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R1803 RES CARBON FILM T 1/4W J 4.7k Ω RCX4472T1001
R1804 RES CARBON FILM T 1/4W J 1.2 Ω RCX41R2T1001
R1805 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
R1806 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R1807 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1808 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1809 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R1810 RES CARBON FILM T 1/4W J 4.7k Ω RCX4472T1001
R1811 RES CARBON FILM T 1/4W J 100k Ω RCX4104T1001
R1812 RES CARBON FILM T 1/4W J 12k Ω RCX4123T1001
R1930 RES CARBON FILM T 1/4W J 47 Ω RCX4470T1001
R1931 RES CARBON FILM T 1/4W J 47k Ω RCX4473T1001
R1932 RES CARBON FILM T 1/4W J 82 Ω RCX4820T1001
R1933 RES CARBON FILM T 1/4W J 82 Ω RCX4820T1001
R1934 RES CARBON FILM T 1/4W J 180 Ω RCX4181T1001
R1935 RES CARBON FILM T 1/4W J 1.5k Ω RCX4152T1001
R1936 RES CARBON FILM T 1/4W J 180 Ω RCX4181T1001
R1937# METAL OXIDE FILM RES. 2W J 0.33 Ω RN02R33ZU001
R1939 RES CARBON FILM T 1/4W J 2.2k Ω RCX4222T1001
R1940 RES CARBON FILM T 1/4W J 220k Ω RCX4224T1001
Ref. No. Description Part No.
R1941 RES CARBON FILM T 1/4W J 220k Ω RCX4224T1001
R1942 RES CARBON FILM T 1/4W J 180k Ω RCX4184T1001
R1943 RES CARBON FILM T 1/4W J 820k Ω RCX4824T1001
R1944 RES CARBON FILM T 1/4W J 820k Ω RCX4824T1001
R1945 RES CARBON FILM T 1/4W J 390k Ω RCX4394T1001
R1946 METAL OXIDE RES. 1W J 47k Ω RN01473ZU001
R1947 METAL OXIDE RES. 1W J 47k Ω RN01473ZU001
R1948 METAL OXIDE RES. 1W J 47k Ω RN01473ZU001
R1967 RES CARBON FILM T 1/4W J 3.9k Ω RCX4392T1001
R1968 RES CARBON FILM T 1/4W J 3.9k Ω RCX4392T1001
R1969 RES CARBON FILM T 1/4W J 3.9k Ω RCX4392T1001
R1970 RES CARBON FILM T 1/4W J 270 Ω RCX4271T1001
R1971 RES CARBON FILM T 1/4W J 3.9k Ω RCX4392T1001
R1972 CHIP RES. 1/10W J 68k Ω RRXAJR5Z0683
R1973 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R1975 CHIP RES. 1/10W F 30k Ω RRXAFR5H3002
R1976 CHIP RES. 1/10W F 30k Ω RRXAFR5H3002
R1977 CHIP RES. 1/10W F 27k Ω RRXAFR5H2702
R1979 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1980 CHIP RES. 1/10W F 360 Ω RRXAFR5H3600
R1981 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1982 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R1983 RES CARBON FILM T 1/4W J 33k Ω RCX4333T1001
R1984 RES CARBON FILM T 1/4W J 15k Ω RCX4153T1001
R1986 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1988 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
MISCELLANEOUS
B13 HEAT SINK PNA A94F0UH 1EM428121
B14 HEAT SINK PNB ASSEMBLY A94F0UH 1EM428123
BC1301 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
BC1500 COIL BEADS CORE FBR07VA850TB-00 LLBF00ZTU020
BC1501 COIL BEADS CORE FBR07VA850TB-00 LLBF00ZTU020
BC1550 COIL BEADS CORE FBR07VA850TB-00 LLBF00ZTU020
BC1551 COIL BEADS CORE FBR07VA850TB-00 LLBF00ZTU020
BC1930 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1931 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
L3 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
T1050# TRANS INVERTER HVT-153 LTZ3PZ0XB009
T1100# TRANS INVERTER HVT-153 LTZ3PZ0XB009
T1150# TRANS INVERTER HVT-153 LTZ3PZ0XB009
T1200# TRANS INVERTER HVT-153 LTZ3PZ0XB009
T1950# TRANS POWER BCK-35-0607 LTT3PC0XB048
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITOR
C108 CAP CERAMIC (AX) 0.1µF/50V/F/Z CA1J104TU062
RESISTORS
R108 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R109 RES CARBON FILM T 1/4W G 10k Ω RCX4103T1002
R111 RES CARBON FILM T 1/4W G 4.7k Ω RCX4472T1002
R112 RES CARBON FILM T 1/4W G 2.7k Ω RCX4272T1002
R113 RES CARBON FILM T 1/4W G 4.7k Ω RCX4472T1002
R114 RES CARBON FILM T 1/4W G 8.2k Ω RCX4822T1002
R115 RES CARBON FILM T 1/4W G 18k Ω RCX4183T1002
SWITCHES
SW101A TACT SWITCH SKHHLMA010 SST0101AL049
SW103A TACT SWITCH SKHHLMA010 SST0101AL049
SW104A TACT SWITCH SKHHLMA010 SST0101AL049
SW105A TACT SWITCH SKHHLMA010 SST0101AL049
Ref. No. Description Part No.
