FUNAI LC320SLX - Page 20

4-8 A91F4DC
(S-5)
(S-5)
[4] Jack CBA
[6] Jack Holder
[5] Power Supply CBA
[7] Digital Main
CBA Unit
[3] Inverter CBA
(S-6)
(S-7)
(S-8)
(S-9)
(S-9)
Shield Box
(S-10)
(S-11)
(S-7)
(S-7)
Fig. D2
