FUNAI LC320SLX - Page 228

20091009 15-108 A91FMEL
IR SENSOR CBA
JUNCTION CBA
SW105A TACT SWITCH SKHHLMA010 SST0101AL049
SW106A TACT SWITCH SKHHLMA010 SST0101AL049
SW107A TACT SWITCH SKHHLMA010 SST0101AL049
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITOR
C113 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
DIODES
D104 LED GREEN 333GT/E(FNA) NPWZ33GTEFNA
D105 LED L-53HT NP4Z000L53HT
RESISTORS
R123 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R124 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R127 RES CARBON FILM T 1/4W J 3.3k Ω RCX4332T1001
R128 RES CARBON FILM T 1/4W J 100 Ω RCX4101T1001
MISCELLANEOUS
CL101 WIRE ASSEMBLY 8P 8PIN/170MM WX1A94F0-001
CL103 WIRE ASSEMBLY 4P 4PIN/250MM WX1A94F0-003
RS102 SENSOR REMOTE RECEIVER KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
JUNCTION CBA
Consists of the following:
----------
CONNECTOR
CN101 242 SERIES CONNECTOR TUC-P08X-B1 WHT
ST
JCTUB08TG002
Ref. No. Description Part No.
