MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
LCD-A2006 A
LCD-B2006 B
LCD-C2006 C
LCD-D2006 D
PARTS produced in CHINA
Ref. No. Mark Description Part No.
A1 FRONT CABINET L4620EA 1EM021481
A3 CONTROL PLATE L4520EA 1EM322205
A4 REAR CABINET L4620EA 1EM021437
A7 FUNCTION KNOB L4520EA 1EM322204
A9 TILT STAND ASSEMBLY L4620EA 1ESA13376
A9-1 STAND COVER L3216UJ 1EM221416
A9-2 ARM HOLDER L3219UK 1EM221304
A9-3 ARM ASSEMBLY L3219UK 1EM221283
A9-4 STAND RUBBER FOOT L4300UA 1EM422534
A9-5 SCREW P-TIGHT M3X8 BIND HEAD+
BLK
GBHP3080
A9-6 SHEET R L3219UK 1EM322093
A9-7 SHEET L L3219UK 1EM322098
A18 FRONT PLATE L4620EA 1EM221414
B3 STAND HOLDER L2500UA 1EM321428
B4 JACK HOLDER L4520EA 1EM121697
B5 CLOTH(10X30XT0.5) B5900UA 0EM404486
B9 INSULATION SHEET L4520EA 1EM423590
B12 TILT STAND HOLDER L3253UD 1EM321693
B13 CLOTH(15X10XT0.5) L9700UA 0EM405038
B14 SPEAKER HOLDER L4620EA 1EM423593
B17 WASHER 10X5XT0.5 L4620EA 1EM423834
B18 CLOTH(10X190XT0.3) L0200UA 1EM420019
B34 CLOTH 10X150XT1.0 1EM421092
CLN310 WIRE ASSEMBLY 2PIN SPEAKER 2PIN
310MM WHITE RED
WX1L4620-004
CLN801 WIRE ASSEMBLY 2PIN 2PIN 360MM
AWG26
WX1L4620-003
L4 SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
L9 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L23 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L25 ASSEMBLED SCREW M3X10 1EM420633A
SP801 SPEAKER S0407F10 DSD0807XQ002
SP802 SPEAKER S0407F10 DSD0807XQ002
ACCESSORY
X1 REMOTE CONTROL NF007RD 192/
ERC001/NF007RD
NF007RD
PARTS produced in EU
Ref. No. Mark Description Part No.
A6 A RATING LABEL L4620EA ----------
A6 B RATING LABEL L4621BB ----------
A6 C RATING LABEL L4622FC ----------
A6 D RATING LABEL L4623RD ----------
L7 DOUBLE SEMS SCREW M4X12 + BLAK FPH34120
L9 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L17 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L21 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L22 SCREW P-TIGHT 3X14 WASHER
HEAD+
GCJP3140
L27 SCREW P-TIGHT M4X18 BIND HEAD+ GBHP4180
PACKING
S1 A CARTON L4620EA 1EM423567
S1 B CARTON L4621BB 1EM423734
S1 C CARTON L4622FC 1EM423737
S1 D CARTON L4623RD 1EM423740
S2 STYROFOAM TOP L4620EA 1EM121694
S3 STYROFOAM BOTTOM L4620EA 1EM121695
S4 SET BAG L0301UB 1EM320014A
S5 A SERIAL NO. LABEL L4620EA ----------
S5 B SERIAL NO. LABEL L4621BB ----------
S5 C SERIAL NO. LABEL L4622FC ----------
S5 D SERIAL NO. LABEL L4623RD ----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2-1! A,B,D OWNERS MANUAL(EN) L4520EA 1EMN21927
X2-2! A,C OWNERS MANUAL(FR) L4520EA 1EMN21928
X2-3! A,C,D OWNERS MANUAL(DE) L4520EA 1EMN21929
X2-4! A,C OWNERS MANUAL(IT) L4520EA 1EMN21930
X2-5! A OWNERS MANUAL(ES) L4520EA 1EMN21931
X2-6! A OWNERS MANUAL(NL) L4520EA 1EMN21932
X2-7! A OWNERS MANUAL(SV) L4520EA 1EMN21933
X2-8! D OWNERS MANUAL(RU) L4523RD 1EMN21936
X2-9! D OWNERS MANUAL(PL) L4523RD 1EMN21937
X2-10! D OWNERS MANUAL(HU) L4622FC 1EMN21938
X2-11! D OWNERS MANUAL(CS) L4523RD 1EMN21939
X2-12! A OWNERS MANUAL(EL) L4520EA 1EMN21934
X2-16! D OWNERS MANUAL(SK) L4523RD 1EMN21940
X2-17! D OWNERS MANUAL(AR) L4523RD 1EMN21942
