ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
LCD MAIN CBA UNIT & LIQUID
CRYSTAL PANEL UNIT
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
LCD-A2006 A
LCD-B2006 B
LCD-C2006 C
LCD-D2006 D
PARTS produced in CHINA
Ref. No. Description Part No.
LCD MAIN CBA UNIT & LIQUID CRYSTAL PANEL
UNIT
1FSA10148
Ref. No. Description Part No.
MMA CBA
Consists of the following:
1ESA13367
MAIN CBA
FUNCTION CBA
IR SENSOR CBA
----------
----------
----------
Ref. No. Description Part No.
MAIN CBA
Consists of the following:
----------
CAPACITORS
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C12 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M or CA0K101SP085
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C15 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M or CA1A101SP085
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTM101
C16 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C17 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M or CA1J1R0SP085
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C18 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C20 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M or CA1C100SP085
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C21 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C501 ELECTROLYTIC CAP. 22µF/50V M H7 or CE1JMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/50V H7 CE1JMAVSM220
C502 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C503 ELECTROLYTIC CAP. 220µF/16V M H7 or CE1CMASSL221
ELECTROLYTIC CAP. 220µF/16V M H7 CE1CMASSM221
C504 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C505 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C506 ELECTROLYTIC CAP. 100µF/10V M H7 or CE1AMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/10V H7 CE1AMAVSM101
C507 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C512 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C513 ELECTROLYTIC CAP. 220µF/6.3V M H7 or CE0KMAVSL221
ALUMINUM ELECTROLYTIC CAP 220µF/6.3V H7 CE0KMAVSM221
C517 ELECTROLYTIC CAP. 100µF/16V M H7 or CE1CMAVSL101
ALUMINUM ELECTROLYTIC CAP 100µF/16V H7 CE1CMAVSM101
C527 ELECTROLYTIC CAP. 10µF/50V M H7 or CE1JMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/50V H7 CE1JMAVSM100
C536 ELECTROLYTIC CAP. 330µF/6.3V M H7 or CE0KMAVSL331
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V H7 CE0KMAVSM331
C601! METALIZED FILM CAP. 0.1µF/250V or CT2E104MS037
! ACROSS THE LINE CAP. 0.1µF/250V K or CT2E104DC011
! ACROSS THE LINE CAP. 0.1U/250V CT2E104DC015
C602! METALIZED FILM CAP. 0.1µF/250V or CT2E104MS037
! ACROSS THE LINE CAP. 0.1µF/250V K or CT2E104DC011
! ACROSS THE LINE CAP. 0.1U/250V CT2E104DC015
C608 CERAMIC CAP. BN 470pF/2KV or CCD3DKA0B471
CERAMIC CAP. 470pF/2KV or CA3D471PAN04
CERAMIC CAP. RB 470pF/2KV or CA3D471TE006
CERAMIC CAP. BL 470pF/2KV CA3D471XF003
C610! CAP ELE LQ SERIES 150µF/400V/M/85 CA2H151NC234
C612 FILM CAP.(P) 0.01µF/50V J or CMA1JJS00103
FILM CAP.(P) 0.01µF/50V J or CA1J103MS029
POLYESTER FILM CAP. (PB FREE) 0.01µF/100V
J
CA2A103DT018
C613 FILM CAP.(P) 0.068µF/50V J or CMA1JJS00683
FILM CAP.(P) 0.068µF/50V J or CA1J683MS029
POLYESTER FILM CAP. (PB FREE) 0.068µF/
100V J
CA2A683DT018
C614 FILM CAP.(P) 0.001µF/50V J or CMA1JJS00102
FILM CAP.(P) 0.001µF/50V J or CA1J102MS029
POLYESTER FILM CAP. (PB FREE) 0.001µF/
100V J
CA2A102DT018
C631! ELECTROLYTIC CAP. 2200µF/25V M or CE1EMZPDL222
! ALUMINUM ELECTROLYTIC CAP 2200µF/25V M
or
CE1EMZNTM222
! ELECTROLYTIC CAP. 2200µF/25V M CE1EMZNDL222
C632! ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
! ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
! ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C633! ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
! ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085
! ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221
C635! ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
! ELECTROLYTIC CAP. 470µF/16V M or CA1C471SP085
! ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C636! ELECTROLYTIC CAP. 220µF/50V M or CE1JMASDL221
! ELECTROLYTIC CAP. 220µF/50V M or CA1J221SP085
! ELECTROLYTIC CAP 220µF/50V M CE1JMASTM221
C637! ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
! ELECTROLYTIC CAP. 470µF/16V M or CA1C471SP085
Ref. No. Description Part No.
To Next Page
